Motor Connector

square flange 140×40

 Input Connect

spline connect  specifications：m=1, z=18,α=20

Suitable Motor

 input torque≤80N·m

Speed Ratio

Plate Wheel Connection Size

6-hole bolts：M14×1.5，center distance φ160

Wheel Distance

Brake Mode

hydraulic disc brake, brake diameterΦ220 (according to users’ needs)

Body Place, Install Ways

RR horizontal (vertical upwards & FT horizontal)
